Full Ceramic Insert Ball Bearings(UC212CE UC213CE UC214CE)

Basic Information
Place of Origin: China
Certification: ISO
Minimum Order Quantity: 1
Price: 1-20
Packaging Details: General Export Packing
Delivery Time: In stock
Payment Terms: T/T, Western Union

Product Description

Full ceramic bearing with high temperature resistance, cold resistance, wear resistance, corrosion resistance, magnetic electrical insulation resistance, oilless self-lubrication, high speed, etc.

The ring and roller of our ceramic bearing adopts full ceramic materials including zirconia (ZrO2), silicon nitride (Si3N4), silicon carbide (SiC), aluminum oxide (Al203).The cage are made of plastic material: PTFE,PEEK,UPE,PVDF,PA66,SUS304,SUS316, which extends the application of ceramic bearing, high temperature resistant, corrosion resistant, anti-magnetic bearings, bearing, electrical insulation bearing, etc.

Product Parameters

Technical specification

Full ceramic bearing of Zro2 materials has perfect properties such as high and low temperature resistance, high pressure resistance, corrosion resistance, anti-magnetic insulation and self-lubrication, Therefore, it can work in special environment in which hybrid ceramic bearing and bearing steel are not applicable.

Full ceramic bearing of Si3N4 material has similar property as ZrO2 material, besides it has lower weigh, good wear resistance, higher hardness, and it can bear higher temperature than ZrO2 material.

SiC material is outstanding in these aspects: higher chemical corrosion resistance, better strength, higher hardness, higher wear resistance, lower frictional properties, and suitable for the highest temperature.

Full ceramic bearing of Al2O3 material uses 99% Al2O3 ceramic, its rolling parts use Al2O3 ceramic as well.



Bearing No. Boundary dimensions(mm) Mass(kg)
d D B S C r/min G ds ZrO2 Si3N4
UC201CE 12 47 31 12.7 17 0.6 4.5 M6 x 1 0.16 0.09
UC202CE 15 47 31 12.7 17 0.6 4.5 M6 x 1 0.15 0.08
UC203CE 17 47 31 12.7 17 0.6 4.5 M6 x 1 0.14 0.07
UC204CE 20 47 31 12.7 17 1 4.5 M6 x 1 0.12 0.07
UC205CE 25 52 34.1 14.3 17V 1 5 M6 x 1 0.17 0.09
UC206CE 30 62 38.1 15.9 19 1 5 M6 x 1 0.27 0.14
UC207CE 35 72 42.9 17.5 20 1.1 6 M8 x 1 0.4 0.21
UC208CE 40 80 49.2 19 21 1.1 8 M8 x 1 0.54 0.29
UC209CE 45 85 49.2 19 22 1.1 8 M8 x 1 0.57 0.3
UC210CE 50 90 51.6 19 24 1.1 9 M10 x 1 0.64 0.34
UC211CE 55 100 55.6 22.2 25 1.5 9 M10 x 1 0.89 0.48
UC212CE 60 110 65.1 25.4 27 1.5 10 M10 x 1 1.2 0.64
UC213CE 65 120 65.1 25.4 27 1.5 10 M10 x 1 1.51 0.8
UC214CE 70 125 74.6 30.2 29 1.5 12 M12 x 1.25 1.68 0.89
UC215CE 75 130 77.8 33.3 30 1.5 12 M12 x 1.25 1.86 0.99
UC216CE 80 140 82.6 33.3 33 2 14 M12 x 1.25 2.17 1.16
UC217CE 85 150 85.7 34.1 36 2 14 M12 x 1.25 2.62 1.39
UC218CE 90 160 96 39.7 37 2 14 M12 x 1.25 3.31 1.76
UC220CE 100 180 108 42 41 2 14 M12 x 1.25 3.46 1.85



Packaging & Shipping



Full Ceramic Insert Ball Bearings(UC212CE UC213CE UC214CE UC215CE UC216CE UC217CE UC218CE UC220CE)

Our Advantages

1. We have over 10 years' experience.
2. OEM or Non-Standard Bearings: Any requirement for Non-standard bearings is easily fulfilled by us due to our vast knowledge and links in the industry.
3. After Sales Service and Technical Assistance: Our company provides after-sales service and technical assistance as per the customer's requirements and needs.
4. Quick Delivery: Our company provides just-in-time delivery with our streamlined supply chain.
5.We attend promptly to any customer questions. We believe that if our customers are satisfied then it proves our worth. Our customers are always given quick support.
