4304 4305 4306 4307 4308 4309 4310 4311 4312 Double Row Deep Groove Ball Bearings

Basic Information
Place of Origin: China
Certification: ISO
Minimum Order Quantity: 1
Price: 1-20
Packaging Details: General Export Packing
Delivery Time: In stock
Payment Terms: T/T, Western Union, PayPal

Product Description

Deep groove ball bearings are the most widely used bearing type and are suitable for many different industries. Matching that versatility across many different applications, they are available in a wide range of designs, variants and sizes.

Here are examples of applications in which deep groove ball bearings might be used:

4304 4305 4306 4307 4308 4309 4310 4311 4312 Double Row Deep Groove Ball Bearings

4304 4305 4306 4307 4308 4309 4310 4311 4312 Double Row Deep Groove Ball Bearings
4304 4305 4306 4307 4308 4309 4310 4311 4312 Double Row Deep Groove Ball Bearings
4304 4305 4306 4307 4308 4309 4310 4311 4312 Double Row Deep Groove Ball Bearings
Product Parameters

Technical specification

Seal type
Open (without cover), metal shields (ZZ), rubber seals (2RS).

Cage
Cage is an important parts. Usually steel cage will be used in deep groove ball bearings, but there are customers
who prefer nylon cage and bronze cage.


Here is the comparison between each standard organization:

ABEC-1, ABEC-3, ABEC-5, ABEC-7, ABEC-9, the larger the number, the higher the precision grade.



ANSI Standard* DIN 620* ISO 492*
ABEC 1 P0 Class Normal
ABEC 3 P6 Class 6
ABEC 5 P5 Class 5
ABEC 7 P4 Class 4
ABEC 9 P2 Class 2


4304 4305 4306 4307 4308 4309 4310 4311 4312 Double Row Deep Groove Ball Bearings

4304 4305 4306 4307 4308 4309 4310 4311 4312 Double Row Deep Groove Ball Bearings

Bearing No. Dimensions(mm) Mass
d D B kg
4202 15 35 14 0.071
4203 17 40 16 0.106
4204 20 47 18 0.165
4304 20 52 21 0.227
4205 25 52 18 0.189
4305 25 62 24 0.365
4206 30 62 20 0.298
4306 30 72 27 0.542
4207 35 72 23 0.46
4307 35 80 31 0.752
4208 40 80 23 0.558
4308 40 90 33 1.01
4209 45 85 23 0.605
4309 45 100 36 1.35
4210 50 90 23 0.651
4310 50 110 40 1.8
4211 55 100 25 0.882
4311 55 120 43 2.29
4212 60 110 28 1.2
4312 60 130 46 2.87
4213 65 120 31 1.59
4313 65 140 48 3.46
4214 70 125 31 1.68
4314 70 150 51 4.21
4215 75 130 31 1.77
4315 75 160 55 5.15
