1010/1015 1045 1065/1085 Carbon Steel Balls

Basic Information
Place of Origin: China
Certification: ISO
Minimum Order Quantity: 1
Price: 1
Packaging Details: General Export Packing
Delivery Time: In stock
Payment Terms: T/T, Western Union, PayPal

Product Description

Carbon steel balls are cost-effective and widely used. Compared with bearing steel balls, low carbon steel balls have less hardness and wear resistance than the latter, and have a shorter service life.

Carbon steel balls are mostly used for hardware accessories, welding or counterweights, such as hangers, casters, slides, simple bearings, toy accessories, electronic accessories, handicrafts, shelves, small hardware, etc.; they can also be used for polishing or grinding medium.

According to the material, it is divided into low carbon steel ball, medium carbon steel ball, high carbon steel ball, the main material is
1010/1015, 1045, 1065/1085, etc..



COUNTRY STANDARD MATERIAL NAME
CHINA YB 10 15 45 85
U.S.A AISI 1010 1015 1045 1085
JAPAN JIS S9CK S15CK S45C SUP3
GEMANY DIN CK10 CK15 CK45




Chemical composition of 1010 carbon steel balls (C10)
C 0.08%--0.10%
Si -------
Mn 0.30%--0.6%
P 0.040% max.
S 0.050% max.
Chemical composition of 1015 carbon steel balls (C15)
C 0.13%-0.18%
Si -------
Mn 0.30%--0.6%
P 0.040% max.
S 0.050% max.



Product Parameters

We can provide the balls with Low Carbon Steel, High Carbon Chrome Alloy,Chrome steel, Stainless Steel,Phosphor Bronze Brass,High Carbon Steel,Medium Carbon Steel, Ceramics.


1010/1015 1045 1065/1085 Carbon Steel Balls
1010/1015 1045 1065/1085 Carbon Steel Balls
1010/1015 1045 1065/1085 Carbon Steel Balls





Inch mm Weight per 1000 balls kg Inch mm Weight per 1000 balls kg
1/64 0.397 0.00026 - 19 27.98
- 0.5 0.00051 3/4 19.05 28.2
1/32 0.794 0.00021 25/32 19.844 31.87
- 1 0.00407 - 20 32.63
3/64 1.19 0.00688 13/16 20.637 35.85
- 1.2 0.00704 - 21 37.77
- 1.5 0.01377 27/32 21.431 40.15
1/16 1.588 0.01632 - 22 43.43
5/64 1.984 0.03187 7/8 22.225 44.78
- 2 0.0326 - 23 49.63
3/32 2.381 0.055 29/32 23.019 49.75
- 2.5 0.0638 15/16 23.812 55.07
7/64 2.778 0.0875 - 24 26.39
- 3 0.1101 31/32 24.606 60.77
1/8 3.175 0.1305 - 25 63.73
- 3.5 0.1749 1 25.4 66.84
9/64 3.572 0.1859 - 26 71.69
5/32 3.969 0.255 1 1/16 26.987 80.17
- 4 0.261 - 28 89.54
11/64 4.366 0.3394 1 1/8 28.575 95.17
- 4.5 0.3716 - 30 110.1
3/16 4.763 0.4406 1 3/16 30.162 111.9-
- 5 0.5099 1 1/4 31.75 130.5
  5.5 0.6786 - 32 133.7
7/32 5.556 0.6996 1 5/16 33.337 151.1
15/64 5.953 0.8605 - 34 160.3
- 6 0.881 1 3/8 34.925 173.8
1/4 6.35 1.044 - 35 174.9
- 6.5 1.12 - 36 190.3
17/64 6.747 1.253 1 7/16 36.512 198.5
- 7 1.399 - 38 223.8
9/32 7.144 1.487 1 1/2 38.1 225.6
- 7.5 1.721 1 9/16 39.687 255
19/64 7.541 1.749 - 40 261
  7.938 2.04 1 5/8 41.275 286.8
- 8 2.088 1 11/16 42.862 321.2
-' 8.5 2.505 1 3/4 44.45 358.2
11/32 8.731 2.715 - 45 371.7
- 9 2.973 1 13/16 46.037 398
23/64 9.128 3.102 1 7/8 47.625 440.6
- 9.5 3.497 1 15/16 49.212 486.1
3/8 9.525 3.525 - 50 509.9
25/64 9.922 3.983 2 50.8 534.7
- 10 4.079 2 1/8 53.975 641.4
12/32 10.319 4.481 - 55 687.6
- 11 5.429 2 1/4 57150 761.3
7/16 11.112 5.597 - 60 881
- 11.5 6.203 2 3/8 60.235 895.4
29/64 11.509 6.219 2 1/3 63.5 1044.4
15/32 11.906 6.884 - 65 1120.1
- 12 7.048 2 5/8 66.675 1209
31/64 12.303 7.596 2 3/4 69.85 1390.1
1/2 12.7 8.355 - 70 1484.7
- 13 8.961 2 7/8 73.025 1558.4
17/32 13.494 10.02 - 75 1720.7
- 14 11.19 3 76.2 1804.7
9/16 14.288 11.9 3 1/8 79.375 2039.8
- 15 13.77 - 80 2088.3
19/32 15.801 13.99 3 1/4 82.55 2094.4
5/8 15.875 16.32 _ 85 2530.9
- 16 16.7 3 1/2 88.9 2865.7
21/32 16.669 18.89 - 90 2993.4
- 17 20.04 - 95 3521.1
11/16 17.462 21.72 3 3/4 95.25 3524.7
- 18 23.79 - 100 4078.8
23/32 18.256 24.82 4 101.6 4277.7
