Zirconia Silicate Beads/ Balls for Grinding and Milling

Basic Information
Place of Origin: China
Certification: ISO
Minimum Order Quantity: 1
Price: 1
Packaging Details: General Export Packing
Delivery Time: In stock
Payment Terms: T/T, Western Union

Product Description

Ceramic balls have excellent performance as special and magnetism resistance, wear and corrosion resistance, lubrication and maintenance free when working, especially high and low-temperature application, etc. They could be used in awful environment and special condition.

Application:

Product Parameters

Zirconium silicate beads are the result of process optimization and continuous upgrading of molding and grinding technology. 65 zirconium silicate beads are formulated using a high-temperature sintering process. The beads have no pores, dense crystal phases, and spherical shapes. Medium hardness and density, with good wear resistance, very suitable for the dispersion and grinding of medium and low viscosity slurry. Among them, the small particle size can be used for spraying polishing materials.

We can provide the balls with Low Carbon Steel, High Carbon Chrome Alloy,Chrome steel, Stainless Steel,Phosphor Bronze Brass,High Carbon Steel,Medium Carbon Steel, Ceramics.

Zirconia Silicate Beads/ Balls for Grinding and Milling
Zirconia Silicate Beads/ Balls for Grinding and Milling
Zirconia Silicate Beads/ Balls for Grinding and Milling



Inch mm Weight per 1000 balls kg Inch mm Weight per 1000 balls kg
1/64 0.397 0.00026 - 19 27.98
- 0.5 0.00051 3/4 19.05 28.2
1/32 0.794 0.00021 25/32 19.844 31.87
- 1 0.00407 - 20 32.63
3/64 1.19 0.00688 13/16 20.637 35.85
- 1.2 0.00704 - 21 37.77
- 1.5 0.01377 27/32 21.431 40.15
1/16 1.588 0.01632 - 22 43.43
5/64 1.984 0.03187 7/8 22.225 44.78
- 2 0.0326 - 23 49.63
3/32 2.381 0.055 29/32 23.019 49.75
- 2.5 0.0638 15/16 23.812 55.07
7/64 2.778 0.0875 - 24 26.39
- 3 0.1101 31/32 24.606 60.77
1/8 3.175 0.1305 - 25 63.73
- 3.5 0.1749 1 25.4 66.84
9/64 3.572 0.1859 - 26 71.69
5/32 3.969 0.255 1 1/16 26.987 80.17
- 4 0.261 - 28 89.54
11/64 4.366 0.3394 1 1/8 28.575 95.17
- 4.5 0.3716 - 30 110.1
3/16 4.763 0.4406 1 3/16 30.162 111.9-
- 5 0.5099 1 1/4 31.75 130.5
  5.5 0.6786 - 32 133.7
7/32 5.556 0.6996 1 5/16 33.337 151.1
15/64 5.953 0.8605 - 34 160.3
- 6 0.881 1 3/8 34.925 173.8
1/4 6.35 1.044 - 35 174.9
- 6.5 1.12 - 36 190.3
17/64 6.747 1.253 1 7/16 36.512 198.5
- 7 1.399 - 38 223.8
9/32 7.144 1.487 1 1/2 38.1 225.6
- 7.5 1.721 1 9/16 39.687 255
19/64 7.541 1.749 - 40 261
  7.938 2.04 1 5/8 41.275 286.8
- 8 2.088 1 11/16 42.862 321.2
-' 8.5 2.505 1 3/4 44.45 358.2
11/32 8.731 2.715 - 45 371.7
- 9 2.973 1 13/16 46.037 398
23/64 9.128 3.102 1 7/8 47.625 440.6
- 9.5 3.497 1 15/16 49.212 486.1
3/8 9.525 3.525 - 50 509.9
25/64 9.922 3.983 2 50.8 534.7
- 10 4.079 2 1/8 53.975 641.4
12/32 10.319 4.481 - 55 687.6
- 11 5.429 2 1/4 57150 761.3
7/16 11.112 5.597 - 60 881
- 11.5 6.203 2 3/8 60.235 895.4
29/64 11.509 6.219 2 1/3 63.5 1044.4
15/32 11.906 6.884 - 65 1120.1
- 12 7.048 2 5/8 66.675 1209
31/64 12.303 7.596 2 3/4 69.85 1390.1
1/2 12.7 8.355 - 70 1484.7
- 13 8.961 2 7/8 73.025 1558.4
17/32 13.494 10.02 - 75 1720.7
- 14 11.19 3 76.2 1804.7
9/16 14.288 11.9 3 1/8 79.375 2039.8
- 15 13.77 - 80 2088.3
19/32 15.801 13.99 3 1/4 82.55 2094.4
5/8 15.875 16.32 _ 85 2530.9
- 16 16.7 3 1/2 88.9 2865.7
21/32 16.669 18.89 - 90 2993.4
- 17 20.04 - 95 3521.1
11/16 17.462 21.72 3 3/4 95.25 3524.7
- 18 23.79 - 100 4078.8
23/32 18.256 24.82 4 101.6 4277.7



Packaging & Shipping

Zirconia Silicate Beads/ Balls for Grinding and Milling



Our Advantages

1. We have over 10 years' experience.
2. OEM or Non-Standard Bearings: Any requirement for Non-standard bearings is easily fulfilled by us due to our vast knowledge and links in the industry.
3. After Sales Service and Technical Assistance: Our company provides after-sales service and technical assistance as per the customer's requirements and needs.
4. Quick Delivery: Our company provides just-in-time delivery with our streamlined supply chain.
5.We attend promptly to any customer questions. We believe that if our customers are satisfied then it proves our worth. Our customers are always given quick support.


Please contact us immediately if you have any questions.
