88500 88011 88501 88013 88014 88502 88016 88602 88503 88603 Extended Inner Ring Ball Bearings

Basic Information
Place of Origin: China
Certification: ISO
Minimum Order Quantity: 1
Price: 1-10
Packaging Details: General Export Packing
Delivery Time: In stock
Payment Terms: T/T, Western Union

Product Description

Deep groove ball bearings are the most widely used bearing type and are suitable for many different industries. Matching that versatility across many different applications, they are available in a wide range of designs, variants and sizes.

Here are examples of applications in which deep groove ball bearings might be used:

88500 88011 88501 88013 88014 88502 88016 88602 88503 88603 Extended Inner Ring Ball Bearings


88500 88011 88501 88013 88014 88502 88016 88602 88503 88603 Extended Inner Ring Ball Bearings
88500 88011 88501 88013 88014 88502 88016 88602 88503 88603 Extended Inner Ring Ball Bearings
88500 88011 88501 88013 88014 88502 88016 88602 88503 88603 Extended Inner Ring Ball Bearings
Product Parameters

Technical specification

Seal type
Open (without cover), metal shields (ZZ), rubber seals (2RS).

Cage
Cage is an important parts. Usually steel cage will be used in deep groove ball bearings, but there are customers
who prefer nylon cage and bronze cage.


Here is the comparison between each standard organization:

ABEC-1, ABEC-3, ABEC-5, ABEC-7, ABEC-9, the larger the number, the higher the precision grade.

ANSI Standard* DIN 620* ISO 492*
ABEC 1 P0 Class Normal
ABEC 3 P6 Class 6
ABEC 5 P5 Class 5
ABEC 7 P4 Class 4
ABEC 9 P2 Class 2



88500 88011 88501 88013 88014 88502 88016 88602 88503 88603 Extended Inner Ring Ball Bearings

88500 88011 88501 88013 88014 88502 88016 88602 88503 88603 Extended Inner Ring Ball Bearings

Bearing No. Dimensions(mm) Load rating
KN
Mass
d D W W2 r C Co KG
88500 10 30 16.401 9 0.6 5.1 2.38 0.041
88011 11 32 15.4 10 0.6 6.82 3.05 0.047
88501 12 32 15.4 10 0.6 6.82 3.05 0.045
88013 13 32 15.4 10 0.6 6.82 3.05 0.043
88014 14 35 14.399 11 0.6 7.65 3.72 0.057
88502 15 35 14.399 11 0.6 7.65 3.72 0.054
88016 16 35 14.399 11 0.6 7.65 3.72 0.052
88602 15 42 17 13 1 11.5 5.42 0.095
88503 17 40 16.601 12 0.6 9.58 4.78 0.075
88603 17 47 18 14 1 13.5 6.58 0.127
Packaging & Shipping



88500 88011 88501 88013 88014 88502 88016 88602 88503 88603 Extended Inner Ring Ball Bearings


Our Advantages

1. We have over 10 years' experience.
2. OEM or Non-Standard Bearings: Any requirement for Non-standard bearings is easily fulfilled by us due to our vast knowledge and links in the industry.
3. After Sales Service and Technical Assistance: Our company provides after-sales service and technical assistance as per the customer's requirements and needs.
4. Quick Delivery: Our company provides just-in-time delivery with our streamlined supply chain.
5.We attend promptly to any customer questions. We believe that if our customers are satisfied then it proves our worth. Our customers are always given quick support.


Please contact us immediately if you have any questions.
