Spherical roller bearings BS2-2222-2RS5/VT143

Basic Information
Place of Origin: China
Certification: ISO
Minimum Order Quantity: 1
Price: 1-20
Packaging Details: General Export Packing
Delivery Time: In Stock
Payment Terms: T/T, Western Union, MoneyGram

Product Description

Spherical roller bearings are designed to accommodate both heavy radial loads and axial loads inboth directions Long
service life. We supply single row spherical roller bearings, double row shpercial roller bearings.

Applications

Spherical roller bearings(BS2-2222-2RS5/VT143 BS2-2222-2RS5K/VT143 BS2-2224-2RS5/VT143 BS2-2224-2RS5K/VT143 BS2-2226-2CS5/VT143 BS2-2226-2CS5K/VT143)


Spherical roller bearings(BS2-2222-2RS5/VT143 BS2-2222-2RS5K/VT143 BS2-2224-2RS5/VT143 BS2-2224-2RS5K/VT143 BS2-2226-2CS5/VT143 BS2-2226-2CS5K/VT143)

Spherical roller bearings(BS2-2222-2RS5/VT143 BS2-2222-2RS5K/VT143 BS2-2224-2RS5/VT143 BS2-2224-2RS5K/VT143 BS2-2226-2CS5/VT143 BS2-2226-2CS5K/VT143)



Product Parameters

Technical specification

Spherical roller bearings have double row rollers, the outer ring has one shared spherical raceway, and the inner ring has two raceways that are inclined at an angle relative to the bearing axis. This ingenious construction makes it self-aligning and therefore not susceptible to axial or bearing housing angle errors or shaft bending.

MB: Solid brass cage, guidance on inner ring
CA: Retaining flanges on the inner ring, guide ring centered on the inner ring, machined brass cage
CC: Flangeless inner ring, guide ring centered on the inner ring, two stamped steel cages
E: Optimized internal design for increased load carrying capacity
2RS: Contact seal, NBR, on one or both sides
K: Tapered bore, taper 1:12
K30: Tapered bore, taper 1:30
C3: Radial internal clearance greater than Normal
W33: Annular groove and three tube holes in the outer ring

Here is the comparison between each standard organization:
ABEC-1, ABEC-3, ABEC-5, ABEC-7, ABEC-9, the larger the number, the higher the precision grade.

ANSI Standard* DIN 620* ISO 492*
ABEC 1 P0 Class Normal
ABEC 3 P6 Class 6
ABEC 5 P5 Class 5
ABEC 7 P4 Class 4
ABEC 9 P2 Class 2


Spherical roller bearings(BS2-2222-2RS5/VT143 BS2-2222-2RS5K/VT143 BS2-2224-2RS5/VT143 BS2-2224-2RS5K/VT143 BS2-2226-2CS5/VT143 BS2-2226-2CS5K/VT143)


Bearing Designation Principal dimensions Rated Load Fatigue Load Limit Limiting speed
dynamic static
d[mm] D[mm] B[mm] C[kN] C0[kN] Pu[kN] [r/min]
25 52 23 49.9 44 4.75 6100
BS2-2206-2RS/VT143 30 62 25 66.1 60 6.4 5100
BS2-2207-2RS/VT143 35 72 28 88.8 85 9.3 4300
BS2-2208-2RS/VT143 40 80 28 98.5 90 9.8 3900
BS2-2208-2RSK/VT143 40 80 28 98.5 90 9.8 3900
BS2-2308-2RS/VT143 40 90 38 155 140 15 3900
BS2-2209-2RS/VT143 45 85 28 104 98 10.8 3500
BS2-2209-2RSK/VT143 45 85 28 104 98 10.8 3500
BS2-2309-2RS/VT143 45 100 42 190 183 19.6 3400
BS2-2210-2RS/VT143 50 90 28 107 108 11.8 3200
BS2-2210-2RSK/VT143 50 90 28 107 108 11.8 3200
BS2-2310-2RS/VT143 50 110 45 228 224 24 3000
BS2-2211-2RS/VT143 55 100 31 129 127 13.7 2900
BS2-2211-2RSK/VT143 55 100 31 129 127 13.7 2900
BS2-2311-2RS/VT143 55 120 49 280 280 30 2800
BS2-2212-2RS/VT143 60 110 34 159 166 18.6 2700
BS2-2212-2RSK/VT143 60 110 34 159 166 18.6 2700
BS2-2312-2RS/VT143 60 130 53 325 335 36 2500
BS2-2213-2RS/VT143 65 120 38 198 216 24 2400
BS2-2213-2RSK/VT143 65 120 38 198 216 24 2400
BS2-2313-2RS/VT143 65 140 56 357 360 38 2400
BS2-2214-2RS/VT143 70 125 38 213 228 25.5 2300
BS2-2214-2RSK/VT143 70 125 38 213 228 25.5 2300
BS2-2314-2RS/VT143 70 150 60 413 430 45 2100
24015-2RS5/VT143 75 115 40 181 232 28.5 2300
BS2-2215-2RS/VT143 75 130 38 217 240 26.5 2200
BS2-2215-2RSK/VT143 75 130 38 217 240 26.5 2200
BS2-2315-2RS/VT143 75 160 64 462 475 48 2100
BS2-2315-2RSK/VT143 75 160 64 462 475 48 2100
BS2-2216-2RS/VT143 80 140 40 243 270 29 2000
BS2-2216-2RSK/VT143 80 140 40 243 270 29 2000
BS2-2316-2RS/VT143 80 170 67 516 530 54 2000
BS2-2316-2RSK/VT143 80 170 67 516 530 54 2000
BS2-2217-2RS/VT143 85 150 44 291 325 34.5 1900
BS2-2217-2RSK/VT143 85 150 44 291 325 34.5 1900
BS2-2218-2RS/VT143 90 160 48 331 375 39 1800
BS2-2218-2RSK/VT143 90 160 48 331 375 39 1800
BS2-2318-2RS5/VT143 90 190 73 637 695 67 1700
BS2-2318-2RS5K/VT143 90 190 73 637 695 67 1700
BS2-2219-2RS/VT143 95 170 51 393 450 45.5 1700
BS2-2220-2RS5/VT143 100 180 55 433 490 49 1600
BS2-2220-2RS5K/VT143 100 180 55 433 490 49 1600
BS2-2320-2CS5/VT143 100 215 82 847 950 88 600
BS2-2320-2CS5K/VT143 100 215 82 847 950 88 600
BS2-2222-2RS5/VT143 110 200 63 572 640 63 1500
BS2-2222-2RS5K/VT143 110 200 63 572 640 63 1500
BS2-2224-2RS5/VT143 20 215 69 652 765 73.5 1400
BS2-2224-2RS5K/VT143 120 215 69 652 765 73.5 1400
BS2-2226-2CS5/VT143 30 230 75 758 930 88 700
BS2-2226-2CS5K/VT143 130 230 75 758 930 88 700



Packaging & Shipping

Spherical roller bearings(BS2-2222-2RS5/VT143 BS2-2222-2RS5K/VT143 BS2-2224-2RS5/VT143 BS2-2224-2RS5K/VT143 BS2-2226-2CS5/VT143 BS2-2226-2CS5K/VT143)

Our Advantages

1. We have over 10 years' experience.
2. OEM or Non-Standard Bearings: Any requirement for Non-standard bearings is easily fulfilled by us due to our vast knowledge and links in the industry.
3. After Sales Service and Technical Assistance: Our company provides after-sales service and technical assistance as per the customer's requirements and needs.
4. Quick Delivery: Our company provides just-in-time delivery with our streamlined supply chain.
5.We attend promptly to any customer questions. We believe that if our customers are satisfied then it proves our worth. Our customers are always given quick support.


Please contact us immediately if you have any questions.
