FR10 FR15 Guide Roller Bearings/ Cylindrical Guide Bearings

Basic Information
Place of Origin: China
Certification: ISO
Minimum Order Quantity: 1
Price: 1-10
Packaging Details: General Export Packing
Delivery Time: In stock
Payment Terms: T/T, Western Union, PayPal

Product Description

The installation and preloaded of the FR.., FR..R and LR, LR...R series guide roller bearings is finished through the eccentric inner ring. While the FR..Z and LR...Z series roller bearings are the concentric structure in design.

There are two blind holes on one side of the inner ring of the eccentric roller bearings, which are used to adjust the clearance.

Product Parameters
FR… Roller for vee bar, eccentric, " V " profile O.D.

FR... Z Roller for vee bar, concentric, " V " profile O.D.

LR… Plain roller, eccentric, crowned O.D. (crown radius R=500mm)

LR...Z Plain roller, concentric, crowned O.D. (crown radius R=500mm)
FR Series Guide Roller Bearings/ Cylindrical Guide Bearings(FR10 FR10Z FR15 FR15Z FR20 FR20Z FR22 FR22Z FR25 FR25Z FR35 FR35Z)
FR Series Guide Roller Bearings/ Cylindrical Guide Bearings(FR10 FR10Z FR15 FR15Z FR20 FR20Z FR22 FR22Z FR25 FR25Z FR35 FR35Z)
FR Series Guide Roller Bearings/ Cylindrical Guide Bearings(FR10 FR10Z FR15 FR15Z FR20 FR20Z FR22 FR22Z FR25 FR25Z FR35 FR35Z)
Bearing No. Dimensions(mm) KN
A B C D e F G H L D1 D2 D3 D4 D5 d d1 DP R Cr Cor
FR10 22.62 10.5 10 1 1 2 6.8 15.4 30 6.4 15 20.8 11 42 9 2.6 3 200 4.9 5.3
FR10Z 22.62 10.5 10 1 0 2 6.8 15.4 30 6.4 15 20.8 11 42 9 2.6 3 200 4.9 5.3
FR15 29.65 12 12 1 1 2 9 18.5 35 8.4 15 23.8 14 53 14 2.6 3 250 7.2 6.8
FR15Z 29.65 12 12 1 0 2 9 18.5 35 8.4 15 23.8 14 53 14 2.6 3 250 7.2 6.8
FR20 36.2 16 15 1 1 3 11 22.5 46 10.5 20 27.7 18 63 20 2.6 3 300 10.2 9.5
FR20Z 36.2 16 15 1 0 3 11 22.5 46 10.5 20 27.7 18 63 20 2.6 3 300 10.2 9.5
FR22 39.4 16 15 1 2 3 11 27.5 46 10.5 20 33 18 70 20 2.6 3 300 24.6 16.2
FR22Z 39.4 16 15 1 0 3 11 27.5 46 10.5 20 33 18 70 20 2.6 3 300 24.6 16.2
FR25 43.42 20.5 20 1 1 3.5 13 27.5 60 13 25 35.6 20 77 24 4.1 4.5 360 16.3 15
FR25Z 43.42 20.5 20 1 0 3.5 13 27.5 60 13 25 35.6 20 77 24 4.1 4.5 360 16.3 15
FR35 61.25 30 25 1 1 7.5 17.5 42 84 17 40 56.9 30 107 35 4.1 4.5 500 28.4 32
FR35Z 61.25 30 25 1 0 7.5 17.5 42 84 17 40 56.9 30 107 35 4.1 4.5 500 28.4 32
LR10   10.5 10 1 1 2 6.8 15.4 30 6.4 15 20.8 11 47   2.6 3 500 4.9 5.3
LR10Z   10.5 10 1 0 2 6.8 15.4 30 6.4 15 20.8 11 47   2.6 3 500 4.9 5.3
LR15   12 12 1 1 2 9 18.5 35 8.4 15 23.8 14 47   2.6 3 500 7.2 6.8
LR15Z   12 12 1 0 2 9 18.5 35 8.4 15 23.8 14 47   2.6 3 500 7.2 6.8
LR20   16 15 1 1 3 11 22.5 46 10.5 20 27.7 18 72   2.6 3 500 10.2 9.5
LR20Z   16 15 1 0 3 11 22.5 46 10.5 20 27.7 18 72   2.6 3 500 10.2 9.5
LR25   20.5 20 1 1 3.5 13 27.5 60 13 25 35.6 20 85   4.1 4.5 500 16.3 15
LR25Z   20.5 20 1 0 3.5 13 27.5 60 13 25 35.6 20 85   4.1 4.5 500 16.3 15
LR35   30 25 1 1 7.5 17.5 42 84 17 40 56.9 30 100   4.1 4.5 500 28.4 32
LR35Z   30 25 1 0 7.5 17.5 42 84 17 40 56.9 30 100   4.1 4.5 500 28.4 32
