Track Roller Bearing LR5201NPP

Basic Information
Place of Origin: China
Certification: ISO
Minimum Order Quantity: 1
Price: 1-10
Packaging Details: General Export Packing
Delivery Time: In stock
Payment Terms: T/T, Western Union

Product Description
LR Series Cam rollers can be used in the heavy loads track or used as an idler wheel. They are widely used in the particular application that the friction should be reduced.

The outer diameter surface of rollers is shaped to the crowned runner surfaces with R500, so make the stresses well when rollers working.

Rollers take the internal structure design of deep groove ball bearings or double row angular contact ball bearings and have a particular thick-walled outer ring, so the rollers can accommodate higher loads.

Rollers are made of the high-quality bearing steel processed by heat treatment and precision grind, and are filled with a long service life, high-grade and multipurposes grease. Rollers take the metal shields (suffix ZZ or KDD ) or rubber seals (suffix 2RS or NPP) to prevent the dust. Some types of the rollers can be made from the corrosion resistance stainless steel.
Product Parameters



Track Roller Bearing( LR5200NPP LR5201NPP LR5202NPP LR5203NPP LR5204NPP LR5205NPP LR5206NPP LR5207NPP)
Track Roller Bearing( LR5200NPP LR5201NPP LR5202NPP LR5203NPP LR5204NPP LR5205NPP LR5206NPP LR5207NPP)
Track Roller Bearing( LR5200NPP LR5201NPP LR5202NPP LR5203NPP LR5204NPP LR5205NPP LR5206NPP LR5207NPP)
Track Roller Bearing( LR5200NPP LR5201NPP LR5202NPP LR5203NPP LR5204NPP LR5205NPP LR5206NPP LR5207NPP)
Track Roller Bearing( LR5200NPP LR5201NPP LR5202NPP LR5203NPP LR5204NPP LR5205NPP LR5206NPP LR5207NPP)
Track Roller Bearing( LR5200NPP LR5201NPP LR5202NPP LR5203NPP LR5204NPP LR5205NPP LR5206NPP LR5207NPP)
Bearing No.
d
D
B
Mass
I N A
S K F
LR5200-X-2RS 10 32 14 70 LR5200 NPP 305700C-2RS1
LR5201-X-2RS 12 35 15.9 80 LR5201 NPP 305701C-2RS1
LR5202-X-2RS 15 40 15.9 110 LR5202 NPP 305702C-2RS1
LR5203-X-2RS 17 47 17.5 170 LR5203 NPP 305703C-2RS1
LR5204-X-2RS 20 52 20.6 230 LR5204 NPP 305704C-2RS1
LR5205-X-2RS 25 62 20.6 340 LR5205 NPP 305705C-2RS1
LR5206-X-2RS 30 72 23.8 510 LR5206 NPP 305706C-2RS1
LR5207-X-2RS 35 80 27 660 LR5207 NPP 305707C-2RS1
LR5200-X-2Z 10 32 14 70 LR5200 KDD 305700C-2Z
LR5201-X-2Z 12 35 15.9 80 LR5201 KDD 305701C-2Z
LR5202-X-2Z 15 40 15.9 110 LR5202 KDD 305702C-2Z
LR5203-X-2Z 17 47 17.5 170 LR5203 KDD 305703C-2Z
LR5204-X-2Z 20 52 20.6 230 LR5204 KDD 305704C-2Z
LR5205-X-2Z 25 62 20.6 340 LR5205 KDD 305705C-2Z
LR5206-X-2Z 30 72 23.8 510 LR5206 KDD 305706C-2Z
LR5207-X-2Z 35 80 27 660 LR5207 KDD 305707C-2Z
LR5208-X-2Z 40 85 30.2 750 LR5208 KDD
