GE...FO 2RS Series Radial Spherical Plain Bearing(GE15FO 2RS GE17FO 2RS GE2OFO 2RS GE25FO 2RS GE30FO 2RS GE35FO 2RS )

Basic Information
Place of Origin: China
Certification: ISO
Model Number: GE...FO 2RS
Minimum Order Quantity: 1
Price: 1-20
Packaging Details: General Export Packing
Delivery Time: In stock
Payment Terms: T/T, Western Union, PayPal

Product Description

Spherical plain bearings are used for applications requiring rotation and oscillation. The rotation takes place on a sliding
surface so the limiting speed is slow.

We can supply high quality and almost all types of spherical plain bearing,

  1. Radial Spherical Plain Bearings
  2. Angular Contact Spherical Plain Bearings
  3. Thrust Spherical Plain Bearings
  4. Non-standard Spherical Plain Bearings
The main series including: GE...ES, GE…ES-2RS, GEZ…ES, GEZ…ES-2RS, GEG…ES, GEG…ES-2RS, GE…LO, GE…HO-2RS, GE…UK, GE…FW, GE…UK-2RS, GE…FW-2RS, GAC, GX…T.

Applications:

Railway engineering
Railway station construction
Bridge building
Construction machinery
Hydraulic steel structures
Roof designs
Power generation
Oil field exploration
Mining and aggregate processing
Wind turbines
Gear drives
Rolling mills
GE...FO 2RS Series Radial Spherical Plain Bearing(GE15FO 2RS GE17FO 2RS GE2OFO 2RS GE25FO 2RS GE30FO 2RS GE35FO 2RS GE40FO 2RS GE45FO 2RS GE50FO 2RS GE60FO 2RS)
GE...FO 2RS Series Radial Spherical Plain Bearing(GE15FO 2RS GE17FO 2RS GE2OFO 2RS GE25FO 2RS GE30FO 2RS GE35FO 2RS GE40FO 2RS GE45FO 2RS GE50FO 2RS GE60FO 2RS)GE...FO 2RS Series Radial Spherical Plain Bearing(GE15FO 2RS GE17FO 2RS GE2OFO 2RS GE25FO 2RS GE30FO 2RS GE35FO 2RS GE40FO 2RS GE45FO 2RS GE50FO 2RS GE60FO 2RS)
Product Parameters

Technical specification

Here is the comparison between each standard organization:
ABEC-1, ABEC-3, ABEC-5, ABEC-7, ABEC-9, the larger the number, the higher the precision grade.
ANSI Standard* DIN 620* ISO 492*
ABEC 1 P0 Class Normal
ABEC 3 P6 Class 6
ABEC 5 P5 Class 5
ABEC 7 P4 Class 4
ABEC 9 P2 Class 2
Specifications:
1) Sliding contact surfaces: Steel vs. Steel.
2) Materials: Both outer race and inner race are made of high chrome bearing steel.
3) Heat treatment: Both outer race and inner race are quenched (hardened), surface phosphorized.
4) Features of structure: With oil groove and oil holes, with an axial split in outer race. With dual seals.
5) Lubricant: molybdenum disulfide.
6) Properties: Heavy duty, good wearability, corrosion resistance, self-alignment, dust proof.
GE...FO 2RS Series Radial Spherical Plain Bearing(GE15FO 2RS GE17FO 2RS GE2OFO 2RS GE25FO 2RS GE30FO 2RS GE35FO 2RS GE40FO 2RS GE45FO 2RS GE50FO 2RS GE60FO 2RS)


GE...FO 2RS Series Radial Spherical Plain Bearing(GE15FO 2RS GE17FO 2RS GE2OFO 2RS GE25FO 2RS GE30FO 2RS GE35FO 2RS GE40FO 2RS GE45FO 2RS GE50FO 2RS GE60FO 2RS)

Bearing No. Dimensions (mm) Load ratings (KN) Mass
d D B C dk r1
min
r2
min
α C Co kg
GE 15 FO 2RS 15 30 16 10 25.0 0.3 0.3 16 21 106 0.049
GE 17 FO 2RS 17 35 20 12 29.0 0.3 0.3 19 30 146 0.083
GE 20 FO 2RS 20 42 25 16 35.5 0.3 0.6 17 48 240 0.153
GE 25 FO 2RS 25 47 28 18 40.7 0.6 0.6 17 62 310 0.203
GE 30 FO 2RS 30 55 32 20 47.0 0.6 1.0 17 79 399 0.304
GE 35 FO 2RS 35 62 35 22 53.0 0.6 1.0 16 99 495 0.408
GE 40 FO 2RS 40 68 40 25 60.0 0.6 1.0 17 127 637 0.542
GE 45 FO 2RS 45 75 43 28 66.0 0.6 1.0 15 156 780 0.713
GE 50 FO 2RS 50 90 56 36 80.0 0.6 1.0 17 245 1220 1.140
GE 60 FO 2RS 60 105 63 40 92.0 1.0 1.0 17 313 1560 2.050
GE 70 FO 2RS 70 120 70 45 105.0 1.0 1.0 16 400 2000 3.010
GE 80 FO 2RS 80 130 75 50 115.0 1.0 1.0 14 488 2440 3.640
GE 90 FO 2RS 90 150 85 55 130.0 1.0 1.0 15 607 3030 5.220
GE 100 FO 2RS 100 160 85 55 140.0 1.0 1.0 14 654 3270 6.050
GE 110 FO 2RS 110 180 100 70 160.0 1.0 1.0 12 950 4750 9.680
GE 120 FO 2RS 120 210 115 70 180.0 1.0 1.0 16 1070 5350 14.010
GE 140 FO 2RS 140 230 130 80 200.0 1.0 1.0 16 1360 6800 19.010
GE 160 FO 2RS 160 260 135 80 225.0 1.1 1.1 16 1530 7650 20.020
GE 180 FO 2RS 180 290 155 100 250.0 1.1 1.1 14 2120 10600 32.210
GE 200 FO 2RS 200 320 165 100 275.0 1.1 1.1 15 2320 11600 45.280
GE 220 FO 2RS 220 340 175 100 300.0 1.1 1.1 16 2550 12700 51.120
GE 240 FO 2RS 240 370 190 110 325.0 1.1 1.1 15 3030 15190 65.120
Packaging & Shipping



GE...FO 2RS Series Radial Spherical Plain Bearing(GE15FO 2RS GE17FO 2RS GE2OFO 2RS GE25FO 2RS GE30FO 2RS GE35FO 2RS GE40FO 2RS GE45FO 2RS GE50FO 2RS GE60FO 2RS)

Our Advantages

1. We have over 10 years' experience.
2. OEM or Non-Standard Bearings: Any requirement for Non-standard bearings is easily fulfilled by us due to our vast knowledge and links in the industry.
3. After Sales Service and Technical Assistance: Our company provides after-sales service and technical assistance as per the customer's requirements and needs.
4. Quick Delivery: Our company provides just-in-time delivery with our streamlined supply chain.
5.We attend promptly to any customer questions. We believe that if our customers are satisfied then it proves our worth. Our customers are always given quick support.


Please contact us immediately if you have any questions.
